cyclone SA Equip Rental

EX DEHUMIDIFIER

PRODUCT CODE : SADH11440

ATEX IECEx UKEX zone-1-2 zone-21-22 madeinuk

The SA CYCLONE EX Dehumidifier provides powerful, essential moisture control for the toughest workplaces, delivering a high capacity of 200 litres per 24 hours. This mobile unit is built for...

Share This:

Hire/Purchase

Total options:
Order total:
- +

Downloads

  • DATASHEET
  • ATEX CERTIFICATE
  • IECEX CERTIFICATE
  • UKEX CERTIFICATE
SKU: SADH11440 Categories: , , , ,

The SA CYCLONE EX Dehumidifier provides powerful, essential moisture control for the toughest workplaces, delivering a high capacity of 200 litres per 24 hours. This mobile unit is built for performance and safety where it counts. It is fully ATEX, IECEx, and UKCA Certified for zones 1 & 2 (gas) and zones 21 & 22 (dust). The unit’s compact size and plug & play design allow for immediate and flexible use, ensuring you can quickly meet climate requirements.

The SA Dehumidifier is exceptionally compact and lightweight, allowing one operator to move it into place and and power it up. The small size also allows it to be placed in difficult to access areas, so that you can provide drying right where it is needed. Whether you need to dry surfaces to allow painting or coating, protect sensitive equipment or stop corrosion, the SA Dehumidifier is a highly effective tool.

The SA CYCLONE EX Dehumidifier provides powerful, essential moisture control for the toughest workplaces, delivering a high capacity of 200 litres per 24 hours. This mobile unit is built for performance and safety where it counts. It is fully ATEX, IECEx, and UKCA Certified for zones 1 & 2 (gas) and zones 21 & 22 (dust). The unit's compact size and plug & play design allow for immediate and flexible use, ensuring you can quickly meet climate requirements. The SA Dehumidifier is exceptionally compact and lightweight, allowing one operator to move it into place and and power it up. The small size also allows it to be placed in difficult to access areas, so that you can provide drying right where it is needed. Whether you need to dry surfaces to allow painting or coating, protect sensitive equipment or stop corrosion, the SA Dehumidifier is a highly effective tool.
CERTIFICATION
Ex II 2 G D
Ex db eb ib mb pb IIB T4 Gb
db ib mb tb pb IIIC T135°C Db
TYPICAL MOISTURE EXTRACTED
200 litres per day (8 litres per hour)
FREE AIRFLOW
690m³/h (406cfm) @ 50Hz
OPERATING TEMPERATURE
-20°C to +50°C
PROTECTION
Refrigerant overpressure protection
Refrigerant leak protection
Tipping protection
Vibration protection
Motor overcurrent protection
Phase rotation protection
DIMENSIONS
800mm(l) x 700mm(w) x 1290mm(h) – not including duct adapters
WEIGHT
200kg exc. cable
INGRESS PROTECTION
IP65
CURRENT DRAW @ 440VAC
Start Up: 22A Run: 15A
3 PHASE SUPPLY
3Ph+E or 3Ph+N+E
DUCTING SIZE
20cm, 30cm, or 40cm
NOISE LEVEL @ 1M
83dBa
CABLE LENGTH
20m (or as required)
Check EX Certified for Zones 1 & 2 (gas) and Zones 21 & 22 (dust)
Check Fully EX tested and certified as complete system
Check Extracts 200 litres of water per 24 hours
Check Exceptionally compact and lightweight
Check IP65 Rated
Check Reduces costly downtime
Check Plug & play
Check Deployable by one person
Check Offshore platforms
Check Oil refineries
Check Vessels and tanks
Check Confined spaces
Check Chemical plants
Check Shipbuilding and repair
Check Utilities
